Specifications
CHANNEL SEPARATION >75dB (1kHz all modes)
DIMENSIONS (Length x Width x Height)
158 x 115 x 35mm (6.2” x 4.6” x 1.4”)
FREQUENCY RESPONSE BAL:
20Hz-80kHz (-3dB)

SE:
20Hz-20kHz (-0.15dB)

GAIN SETTINGS MM:
36dB

MC High:
48dB

MC Low:
60dB

MC V-Low:
72dB
INPUT IMPEDANCE MM:
47KΩ (100/200pF)

MC High:
47kΩ (100/200pF)

MC Low:
1k/400/100Ω

MC V-Low:
1k/400/100Ω
MAXIMUM OUTPUT VOLTAGE BAL:
100kΩ: ≥19.98V (THD+N <1%), 600Ω: ≥12.75V (THD+N <1%)

SE:
100Ω

NET WEIGHT 456g
OUTPUT IMPEDANCE BAL:
200Ω

SE:
100Ω
POWER CONSUMPTION No Signal ~1.5W; Max Signal ~1.8W
SNR MM:
91dB(A)/82dB (unweighted 80kHz BW)

MC High:
81dB(A)/72dB (unweighted 80kHz BW)

MC Low:
89.6dB(A)/80dB (unweighted 80kHz BW)

MC V-Low:
78.6dB(A)/69dB (unweighted 80kHz BW)
TOTAL HARMONIC DISTORTION MM:
<-91dB/0.0027%

MC High:
<-80dB/0.0095%

MC Low:
<-70dB/0.031%

MC V-Low:
1k/400/100Ω
POWER SUPPLY REQUIREMENT DC 5V/0.5A (centre positive)

‍
