Specifications
ANALOGUE INPUTS SE RCA L/R:
2.0V nominal @ 0dBFS, 1MegOhm Zin

SE 3.5mm:
1.0V nominal @ 0dBFS, 1 MegOhm Zin

BAL 4.4mm:
4.0V nominal @ 0dBFS, 24kOhm Zin
DIMENSIONS 158x117x35mm (6.2x4.6x1.4”)
DNR Line Section:
≥119dB(A)

Headphone Section:
BAL 4.4mm: ≥119dB(A) @ 0dBFS
SE 6.35mm: ≥119dB(A) @ 0dBFS
FREQUENCY RESPONSE 10Hz-200kHz (-3dB)
GAIN 0dB, 6dB, 12dB, 18dB
HEADPHONE OUTPUT MAX Headphone Section:
BAL 4.4mm:>15.1V/385mW (@ 600 Ohms), >6.2V/1,200mW (@ 32 Ohms)
SE 6.35mm: >7.6V/98mW (@ 600 Ohms), >7.2V/1,600mW (@ 32 Ohms)
HEADPHONE OUTPUT RMS Headphone Section:
BAL 4.4mm: >11.5V/2,000mW (@ 64 Ohms)
SE 6.35mm: >7.2V/1,600mW (@ 32 Ohms)
INPUT VOLTAGE DC:
5V/2.5A
AC 100-240V, 50/60Hz
MAXIMUM INPUT LEVEL SE RCA:
3.8V RMS

SE 3.5mm:
1.92V RMS

BAL 4.4mm:
7.4V RMS
NET WEIGHT 495g (1.09 lbs)
OUTPUT IMPEDANCE Line Section:
<200 Ohms

Headphone Section:
BAL 4.4mm HP: <2 Ohms
SE 6.35mm HP: <1 Ohm
POWER CONSUMPTION No Signal: ~5W
Max Signal: ~13W
SNR Line Section:
≥125dB (7.3V 4.4mm Input 0dB @ 200kOhm)

Headphone Section:
BAL 4.4mm: ≥125dB (7.3V 4.4mm Input 0dB @ 600 Ohms)
SE 6.35mm: ≥122dB (1.9V Input 0dB @ 600 Ohms)
THD+N Line Section:
0.006% (0dB 200kOhm load)

Headphone Section:
BAL 4.4mm: <0.006% (@ 360 mW/2.4V 16 Ohms)
SE 6.35mm: <0.006% (@ 100mW/1.27V 16 Ohms)

‍
