Specifications
CHIPSET Bluetooth:Qualcomm QCC518x Series.
DSP:CT5302
DAC:ES9023
Amp:MAX97220
DNR 109dB (0dBFS @ 1kHz)
INPUT RX Mode:Bluetooth 5.4 (aptX Lossless, aptX Adaptive, aptX, LDAC, LHDC/HWA, AAC, SBC)
TX Mode:USB, Optical, Coaxial, RCA L/R (Analogue)
DAC Mode:USB, Optical, Coaxial, RCA L/R (Analogue)
MAXIMUM SUPPORTED SAMPLE RATE RX Mode:96kHz/24Bit
TX Mode:96kHz/24Bit
DAC Mode:96kHz/24Bit (USB), 192kHz/24Bit (Optical/Coaxial)
NET WEIGHT 447 g (0.99 lbs)
OUTPUT IMPEDANCE Balanced 4.4mm:≤102Ω
Single-Ended RCA:≤51Ω
OUTPUT VOLTAGE Balanced 4.4mm:4.1Vrms (0dBFS@1kHz)
Single-Ended RCA:2.05Vrms (0dBFS@1kHz)
SNR 109dB
THD+N < 0.005% (10K Load)@(20-20kHz)
POWER SUPPLY REQUIREMENT USB-C or DC 5V/≥0.5A (centre +ve)

‍
