Technical Specifications

• Product Type: Streaming Expansion Module & Standalone Network Streamer / Transport
• Operating Modes: Dual Operation (Expansion Mode & Standalone Mode)

Audio Performance & Playback

• Supported Audio Formats: Linear PCM up to 32-bit/384kHz, DSD up to DSD128, MQA, FLAC, WAV, ALAC, AIFF
• Resolution Specs:
  • TIDAL Connect & Qobuz Connect: Up to 24-bit / 192kHz
  • Google Cast: Up to 24-bit / 96kHz
  • Spotify Connect: Up to 24-bit / 44.1kHz
• Analogue Output Level: 2 V RMS
• Analogue Output Impedance: 10 Ω

Connectivity & Streaming

• Streaming Protocols: TIDAL Connect, Qobuz Connect, Spotify Connect, AirPlay 2, Google Cast, Roon Ready, DLNA/UPnP
• Network Connectivity:
  • Ethernet (10/100 Base-T)
  • Dual-band Wi-Fi (802.11 a/b/g/n/ac)
• Bluetooth: Bluetooth 5.2 (A2DP 1.3.2, AVRCP 1.6.2)

Input / Output Interfaces

• Digital Inputs:
  • 1× Optical S/PDIF (up to 24-bit / 192kHz)
  • 1× USB-C (Host / Power)
• Outputs:
  • 1× Stereo RCA Analogue Output
  • 1× Optical S/PDIF Output
  • 1× USB-C Digital Audio Output

Control & App

• Control App: ROSE AIR App (iOS & Android)
• Display Sync: Supports intelligent UI synchronization to mirror playback status and album art when attached to display-equipped host systems.

Physical Specifications

• Dimensions (W × D × H): 110 × 115.5 × 27 mm
• Net Weight: 245 g

‍
