Specification

TRANSDUCER

   Tweeter 0.75" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers 4” Turbine Cone
   Overall Frequency Response 50 – 50kHz (when wall mounted)
   Frequency Response (-3dB limits) 70 – 32kHz (when wall mounted)
   Recommended Amplifier Power 45 - 100W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 4.2Ω
   Sensitivity (2.83V/1m) 85.5dB (when wall mounted)

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 2100
   Mid-range/Mid-bass Crossover Frequency -

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 166 x 158.3 x 320mm
   6.5 x 6.2 x 12.6 in
   Product Weight (each) 6.6 lbs/3 kg
   Shipping Weight 16 lbs/7.3 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Sealed
   Available Finishes Black / Walnut / White
   Feet Pads
   Wall-Mountable (keyhole slots) Yes
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified N/A
   Shipping Dims (WxHxD) 415 x 370 x 260mm
   (16.3 x 14.6 x 10.2) in

‍
