Specification

TRANSDUCER

   Tweeter 1" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers Two 6 ½” Turbine Cone
   Overall Frequency Response 36Hz - 50kHz
   Frequency Response (-3dB limits) 48Hz - 39kHz
   Recommended Amplifier Power 20 - 200W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 4.1Ω
   Sensitivity (2.83V/1m) 89dB

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 2500
   Mid-range/Mid-bass Crossover Frequency -

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 615 x 196.6 x 350mm
   24.2 x 7.8 x 13.8 in
   Product Weight (each) 32.8 lbs/14.9 kg
   Shipping Weight 39.5 lbs/17.9 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Dual Rear X-Ports
   Available Finishes Black / Walnut
   Feet Rubber pads
   Wall-Mountable (keyhole slots) No
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified Yes
   Shipping Dims (WxHxD) 740 x 483 x 293mm
   (29.1 x 19 x 11.5) in

‍
