Specification

TRANSDUCER

   Tweeter 1" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers Four 4” Turbine Cone
   Overall Frequency Response 50Hz - 50kHz
   Frequency Response (-3dB limits) 75Hz - 35kHz
   Recommended Amplifier Power 25 - 200W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 3.9Ω
   Sensitivity (2.83V/1m) 87dB

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 2700
   Mid-range/Mid-bass Crossover Frequency 1400

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 762 x 141 x 187.5mm
   30 x 5.5 x 7.4 in
   Product Weight (each) 20 lbs/9 kg
   Shipping Weight 23.7 lbs/10.8 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Sealed
   Available Finishes Black / Walnut / White
   Feet Rubber pads
   Wall-Mountable (keyhole slots) Yes
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified No
   Shipping Dims (WxHxD) 867 x 264 x 230mm
   (34.1 x 10.4 x 9) in

‍
