Specification

TRANSDUCER

   Tweeter 1" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers Two 5 ¼” Turbine Cone
   Overall Frequency Response 45Hz - 50kHz
   Frequency Response (-3dB limits) 65Hz - 38kHz
   Recommended Amplifier Power 30 - 200W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 3.8Ω
   Sensitivity (2.83V/1m) 86.5dB

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 2200
   Mid-range/Mid-bass Crossover Frequency -

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 482.6 x 172 x 226.5mm
   19 x 6.8 x 8.9 in
   Product Weight (each) 16.8 lbs/7.6 kg
   Shipping Weight 19.8 lbs/9 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Sealed
   Available Finishes Black / Walnut
   Feet Rubber pads
   Wall-Mountable (keyhole slots) No
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified No
   Shipping Dims (WxHxD) 598 x 316 x 260mm
   (23.5 x 12.4 x 10.2) in

‍
