Specification

TRANSDUCER

   Tweeter 1" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers 6 ½” Turbine Cone
   Overall Frequency Response 39Hz - 50kHz
   Frequency Response (-3dB limits) 51Hz - 38kHz
   Recommended Amplifier Power 30 - 200W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 3.8Ω
   Sensitivity (2.83V/1m) 86dB

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 3000
   Mid-range/Mid-bass Crossover Frequency -

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 190 x 359 x 353.8mm
   7.5 x 14.1 x 13.9 in
   Product Weight (each) 19.1 lbs/8.7 kg
   Shipping Weight 43.4 lbs/19.7 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Rear X-Port
   Available Finishes Black / White
   Feet Rubber pads
   Wall-Mountable (keyhole slots) No
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified No
   Shipping Dims (WxHxD) 533 x 448 x 452mm
   (21 x 17.6 x 17.8) in

‍
