Dimensions (W × H × D)
431 x 144 x 425 mm
17” x 5 7/8” x 16”

FRONT PANEL HEIGHT
132.6 mm / 5 1/4”

Power Requirements
120V, 60Hz

Power Consumption
380W

Standby Power Consumption
<0.5W

Net Weight
15.7 kg, 34.6 lbs

BTU RATING (4Ω, 1/8th power)
1027 BTU/h

Power Output
220 Watts / ch (4 Ohms)
140 Watts / ch (8 Ohms)

Total Harmonic Distortion
(THD)
<0.03%

Frequency Response
Line Level Inputs:
10Hz - 100kHz, ±0.5dB
Digital Inputs:
10 Hz – 70k Hz, (±3 dB, MAX)

S/N Ratio (IHF "A" Weighted)
Line Level Inputs: 103dB
Digital Inputs: 105dB

‍
