Specifications
ANALOGUE INPUTS Single-Ended RCA (L/R)
BLUETOOTH FORMATS aptX Lossless, aptX Adaptive, aptX, LDAC, LHDC/HWA, AAC, SBC
DIGITAL INPUTS Bluetooth 5.4;
USB-B 3.0;
S/PDIF Coaxial;
S/PDIF Optical;
DIMENSIONS 214 x 158 x 41mm (8.4 x 6.2 x 1.6”)
FILE SUPPORT 768kHz PCM; DSD512 (22.6 MHz)
HEADPHONE OUTPUT Balanced 4.4mm; Single-Ended 6.3mm
HEADPHONE OUTPUT IMPEDANCE ≤1Ω; ≤7Ω when iEMatch enabled
HEADPHONE OUTPUT RMS 4.4mm ≥12.7V/2,532mW @ 64Ω (RMS)
6.3mm ≥8.4V/2,244mW @ 32Ω (RMS)
LINE OUTPUTS Balanced XLR (L/R): ≤19.5V (variable); 4.4V (fixed)
Single-Ended RCA (L/R): ≤10.5V (variable); 2.2V (fixed)
LINE OUTPUT IMPEDANCE XLR ≤102Ω; RCA ≤51Ω
NET WEIGHT 916g (2.0lbs)
SNR+DNR ≥120dB(A) @ -60dBFS
THD+N ≤0.0015% @ 0dBFS
POWER SUPPLY REQUIREMENT DC 9V/1.5A-15V/0.9A (centre +ve)

‍
