Specifications
DIMENSIONS 256 × 185 × 120 mm (10.1" x 7.3" × 4.7")
ESL OUTPUT VOLTAGE Custom/Pro640V RMS max
Normal320V RMS max.
FREQUENCY RESPONSE 0.5Hz to 500kHz(-3dB)
GAIN 0dB, 9dB and 18dB user-selectable
INPUT VOLTAGE DC 12V/4A or 15V/3A (Phantom iCAN)
MAXIMUM OUTPUT POWER Balanced>15,000mW (@ 16Ω)
UnBAL>5,760mW (@ 16Ω)
MAXIMUM OUTPUT VOLTAGE Balanced>27.0V (@ 600Ω)
UnBAL>14.0V (@600Ω)
NET WEIGHT 4.2 kg (9.3 Ibs)
POWER CONSUMPTION < 27W idle, 75W max
RMS OUTPUT POWER Balanced>9,030mW (@ 32Ω)
UnBAL>3,120mW (@ 32Ω)
SNR Balanced>145dB(A)
UnBAL> 130dB(A)
THD+N Solid state
Balanced: ≤0.0015%
Unbal: ≤0.007%

Tube
Balanced: ≤0.002%
Unbal: ≤0.006%

Tube plus
Balanced: ≤0.012%
Unbal: ≤0.2%

‍
