ALVA RANGE

MAX POWER CONSUMPTION         10W
CARTRIDGE SUPPORT         Moving Magnet | Moving Coil
Gain @ 1kHz         MM: 39dB | MC: 60dB
NOMINAL OUTPUT         300mV
SENSITIVITY FOR NOMINAL OUTPUT         MM: 3.35mV | MC: 305uV
EQUIVALENT INPUT NOISE (A-WEIGHTED)         MM: ~0.09uV | MC: ~0.08uV
RIAA CURVE ACCURACY         +/- 0.3dB 30Hz-20kHz
SIGNAL TO NOISE RATIO GROUNDED INPUTS REF. 1V output (20Hz-20kHz BW)         MM: >90dB | MC: >70dB
THD+N 1kHz (20-20kHz BW)         MM: <0.0025% | MC: <0.20%
INPUT IMPEDANCE         MM: 47k Ohms | MC: 100 Ohms
INPUT CAPACITANCE         100pF
OVERLOAD MARGIN         >30dB
CROSSTALK @ 10kHz         MM: >85dB | MC: 75dB
DIMENSIONS (H x W x D)         48 x 215 x 159 mm (1.9 x 8.5 x 6.2")
WEIGHT         0.95kg (2.1lbs)

‍
