DAC RANGE

DIGITAL TO ANALOGUE CONVERTERS         Dual ESS ES9028Q2M DACs
DIGITAL FILTER         Selectable, Fast – Slow – Short delay
FREQUENCY RESPONSE         10Hz to 50kHz (±1dB)
THD+N @ 1KHZ 0DBFS         <0.0005% (A-Weighted)
SIGNAL TO NOISE RATIO         >115dB (A-Weighted)
CROSSTALK @ 10KHZ         < -110dB
OUTPUT IMPEDANCE         <50 Ohms (unbal), <100 Ohm (bal)
MAX. OUTPUT LEVEL (UNBALANCED)         2.1V rms (fixed or variable – user selectable)
MAX. OUTPUT LEVEL (BALANCED)         4.2V rms (fixed or variable – user selectable)
DIGITAL INPUT WORD WIDTHS SUPPORTED         16bit (Bluetooth), 16-24bit (Optical, Coaxial), 16-24bit (USB)
DIGITAL INPUT SAMPLING FREQUENCIES SUPPORTED         44.1kHz to 96kHz PCM, DoP64 (Optical), 44.1kHz to 192kHz PCM, DoP64 (Coaxial), 44.1kHz to 768kHz PCM, Native DSD 64x to 512x, DoP 64x to 256x (USB)
MQA COMPATIBILITY         Full decoding (Core + Renderer)
BLUETOOTH         v4.2, A2DP profile, SBC and AptX codecs
ROON TESTED         Yes
HEADPHONE OUTPUT THD+N         < 0.001% at 1kHz 0dBFS @ 100mW into 32ohm
HEADPHONE OUTPUT S/N         > 115dB (A-Weighted)
MAX OUTPUT POWER         >300mW @ 32ohm, >65mW @ 150ohm
FREQUENCY RESPONSE         10Hz - 50kHz (±1dB)
RECOMMEND HEADPHONE IMPEDANCE         10 Ohm to 600 Ohm
MAX POWER CONSUMPTION         12W
COLOUR         Lunar Grey
DIMENSIONS (HXWXD)         52 x 215 x 191mm; (2.0 x 8.6 x 7.6”)
WEIGHT         1.2kg/2.6lbs

‍
