AX RANGE

THD @ 1Khz -10dBFs         <0.01%
D/A Convertor         Wolfson Microelectronics WM8524
Gapless Playback         Yes
Filter         2 -pole Butterworth filter
Frequency response (+/-0.4dB)         20Hz - 20kHz
THD @ 1Khz 0dBFs         <0.006%
S/N ratio, A weighted         >95dB
Crosstalk @1kHz         <-98dB
Crosstalk @20kHz         <-95dB
Output impedance         <50 ohms
Maximum power consumption         15W
Standby power consumption         <0.5W
Dimensions         75 x 430 x 305mm (3.0 x 16.9 x 12.2”)
Weight         4.3kg (9.5lbs)
S/PDIF Output Impedance         <75 ohms

‍
